Kelly Bonestock

Kelly® production Bonestock, available in 5 production sizes and are “built per order”.

  • Material: True Temper OX Platinum
  • Available in 5 “production” sizes (see chart below)
  • Weight: 1.5 – 1.9kg  (V53 – V61)
  • Finish – single stage powdercoat, top mount decals
  • Ritchey investment cast dropouts, 130mm spacing
  • Brake – standard short reach caliper
  • Head Tube – standard 1.125″
  • Seat tube – 1.125″ to accept 27.2 seat post
  • Flared or 44mm head tube – add $150
  • 12mm through axle – $250
  • Disc brake – add $250
  • Clear over decal upgrade – add $150
  • Custom color upgrades available – call for quote
  • Lead times vary depending on current production schedule
  • US flat fee shipping – $60

…

what size Bonestock are you?

SIZING/GEOMETRY
Kelly® measures
Seat-Tube center of BB to top of top tube and TheoreticTop Tube center to center.
Seat-tube x Top tube V53 (48×53) V55 (50×55) V57 (57×57) V59 (59×59) V61 (61×61)
Seat/Head Tube Angle 73º/71.5º 73º/73º 73º/73º 73º/73º 72º/73º
BB Height 10.5″ 11″ 11″ 11″ 11″
Chainstay Length 16.25″ 16.25″ 16.25″ 16.25″ 16.25″
Standover 75cm
29 1/2″		 80.7cm
31 3/4″		 82.6cm
32 1/2″		 84.5cm
33 1/4″		 86.1cm
33 7/8″
Wheelbase 97.5 cm
38 1/4″		 98.3 cm
38 5/8″		 100.2 cm
39 3/8″		 102.2 cm
40 1/4″		 103.4 cm
40 5/8″
